EOTECH Commercial Low Power ATPIAL BLK

ATPIAL Targer Pointer/Illuminator/Aiming Laser

Description

The Advanced Target Pointer/Illuminator/Aiming Laser (ATPIAL) is small, lightweight and easy to use. The aiming system has integrated infrared and visible aiming lasers and an infrared illuminator. The ATPIAL (AN/PEQ-15) has been battle-tested for use on small arms and crew-served weapons. This device is the U.S. Armed Forces standard for night direct-fire aiming and illumination.Some models are restricted for use by law enforcement and military organizations. Contact EOTech at 888-368-4656 or email for more information.The ATP-000-A18Vis is a visible only model that was created to support tactical training requirements for law enforcement and military organizations.

Product Details

Length/Width/Height:

4.6” x 2.8” x 1.6” (117 mm x 71 mm x 41 m)

Weight:

7.5 oz with batteries

Battery Power:

One 3-volt DL123 battery

Visible Aim Laser - ATPIAL

Output: 4.0 mW (Class IIIa)

Beam Divergence: 0.5 mrad

Wavelength: 605-665 nm

Range: > 25 m

IR Aiming Laser - ATPIAL

Output Power Low: 0.6 mW (Class I)

Output Power High: 25 mW (Class IIIb)

Beam Divergence: 0.5 mrad

Wavelength: 820-850 nm

Range: > 600 m (Low), 2000 m (High)

IR Illuminator - ATPIAL

Output Power Low: 3.5 mW (Class IIIa)

Output Power High: 30 mW (Class IIIb)

Beam Divergence: 1-105 mrad (minimum)

Wavelength: 820-850 nm

Range: > 2,000 m

Danger: Laser Radiation

Avoid direct exposure to beam

IR Laser

Power: 50 mW

Wavelength: 830 nm

Class IIIb

VIS Laser

Power: < 5 mW

Wavelength: 650 nm

Class IIIa
